Technical data of the TM 210 x 400 Vario Metal lathe with digital display. | |
| Turning diameter above the bed | 210 mm. |
| Turning diameter above the cross support | 115 mm. |
| Center height | 105 mm. |
| Distance between the centers | 400 mm. |
| Bed width | 100 mm. |
| Relocation of the cross support | 75 mm. |
| Relocation of the cone support | 55 mm. |
| Passage of the main axis | 21 mm. |
| Chuck plate recording | Flange mounting. |
| Recording of the main axis | MC 3. |
| Speed range continuously adjustable from | 0 - 2500 RPM. |
| Thread cutting range imperial | 10 - 44 TPI. (8 positions) |
| Metric thread cutting range | 0.5 - 3 mm. (11 positions) |
| Stroke of the pinole | 65 mm. |
| Diameter of the pinole | 30 mm. |
| Recording of the pinole | MC 2. |
| Engine power | 750 watts / 1 hp. |
| Voltage | 230 volts. |
| Weight | 76 kg. |
| Packaging dimensions | 88 x 48 x 46 cm. |
This metal lathe is supplied as standard. | |
| |
| |
| |
| |
| |
| |
| |
| |
| |
| |
| |
|
